Electronic Fuse Block

Electronic Fuse Block - Universal

• Compact in size; 1-1/8” x 2-3/4” x 3-3/4”. Easily mounts to the battery, eliminating all other direct battery connection needs
• 20 A fuse and separate 30 A relay isolate all your electrical accessories from the bike’s electrical system
• Includes 3 keyed power connections, 2 always on power connections protected by a combination of 5 A and 10 A fuses
• Can be used as a trailer isolating wiring
• Separate left and right turn signal connection terminals, 2 running light and 2 brake light terminal blocks, all protected by four 8 A , 277 V automatic switch relays for complete isolation
• Universal application
